Machines for coiling, heat cutting, and binding ropes; automatic coiling machines; wire measuring and coiling machines; automatic tying machines; tying machines for wires/cables bundles; wire tying machine.
Applicable wire diameter 4 mm
Cutting line length: 1.5-5m
Winding tie shape: single tie with 8 characters, head and tail with the same side
Winding spacing: 80-120mm
Tie diameter: ≤40mm
Head and tail length: 130-150mm
Production efficiency: ≤800PCS/H(1.8m)
Applicable binding tape-coated iron core ≤5KG/ roll
Applicable pressure 0.5-0.65mpa
Applicable power supply 220V/50Hz
Machine power: 2800W
Machine weight: about 230KG
Machine size: 1060L*800W*1600H
automatic coiling machine wire measuring & coiling machine
